ULTRAFLOW®4000 ULTRASONIC FLOW METER SENSOR
The ULTRAFLOW®4000 is an ultrasonic flow meter sensor designed for measuring both conductive and non-conductive liquids, including corrosive ones like strong acids. It features no moving parts, negligible pressure drop, and can measure various flow types, such as continuous, dosing, and pulsating. Key features include a large backlit LCD display, multiple output options (analog, pulse, alarm), and options for easy installation with clamp-on sensors.
- PVC-CPVC True Union Ends (Optional)</span>
- Suitable for Dosing | Pulsating Flows
- Display; Flow Rate + Totalizer
- 4-20mA Output + Pulse Relay
- Negligible Pressure Drop</span>
Specifications
ULTRAFLOW®4000 ULTRASONIC FLOW METER SENSOR Key Specification
Wetted Materials: All plastic polysulfoneAccuracy±1.0% of reading (with option) or ±2.0% of reading Outputs4-20mA + Pulse RelayRS-485
Operating Temperature: (Medium)(-10^{circ }C) to (80^{circ }C) ((14^{circ }F) to (176^{circ }F))Ambient
Temperature:(-20^{circ }C) to (+60^{circ }C) ((-4^{circ }F) to (140^{circ }F))
Pressure Rating: (Max)10 bar (145 psi)
Protection Class :IP67 / NEMA 4X
Flow Rate: (Example)0.3 – 21 LPM for a 1/2″ model
Pressure Drop: Negligible Features Empty pipe alarm, air bubble detection Suitable for dosing and pulsating flows Measures both conductive and non-conductive liquidsM12
Quick Disconnect:connector Display for flow rate and totalizer
