Dwyer Series BBV-1 3-Valve Block Manifold | 6000 psi 316 SS Valve

DWYER SERIES BBV-1 3-VALVE BLOCK MANIFORD  | 6000 PSI 316 SS VALVE

  • Accuracy: ±3% of full scale.
  • Maximum Pressure: 10 psi (70 kPa).
  • Maximum Temperature: 140°F (60°C).
  • Body Material: Molded white styrene plastic.
  • Fluid Types: Red gage oil (0.826 sp. gr.) or Blue water (1.0 sp. gr.) depending on model.
  • Standard Accessories: Two tubing connectors, mounting screws, fluid, and red/green pointer flags.

DWYER SERIES BBV-1 3-VALVE BLOCK MANIFORD  | 6000 PSI 316 SS VALVE

The Series BBV-1 is forged from 316 stainless steel bar stock, ensuring exceptional strength and corrosion resistance. Its three-valve architecture consists of two isolate valves and one equalizing valve, allowing for the safe removal of instrumentation without process interruption. The manifold features precision-machined hard seats to reduce operating torque and PTFE stem packing for a long, leak-free service life.

PRODUCT USES:

  • Instrumentation Isolation: Safe removal or calibration of industrial pressure gauges and transmitters.
  • Oil & Gas: Critical flow control in refineries and petrochemical processing plants.
  • Power Generation: Reliable service in nuclear power stations and demanding fluid systems.
  • Differential Pressure Control: Equalizing pressure across DP devices during maintenance or startup.







Technical Sheets

Instruction Manual

Catalog Page

Specifications

DWYER SERIES BBV-1 3-VALVE BLOCK MANIFORD  | 6000 PSI 316 SS VALVE – KEY SPECIFICATIONS

  • Pressure Limit: 6,000 psi (400 bar).
  • Temperature Limit: 464°F (240°C).
  • Wetted Materials: 316 Stainless Steel (body, stem, and valve assembly); PTFE stem packing.
  • Service Compatibility: Compatible liquids, gases, or steam.
  • Connections: Available in 1/2″ female NPT or DIN 19213 flanged variants.
  • Operational Durability: Designed to withstand repeated open and close cycles in mission-critical systems.
