SERIES ACI Q8 B8

ACI Q8/B8 SERIES | EXPLOSION-PROOF BACnet & MODBUS DETECTORS

The Q8/B8 Series features a NEMA 4X (IP66) aluminum die-cast enclosure suitable for Class I, Division 1 & 2 environments. Each unit includes a backlit LCD that displays real-time gas concentrations, STEL, TWA, and peak daily values. Setup is completed via non-intrusive magnetic switches, allowing calibration without opening the housing.

PRODUCT USES:

Mechanical rooms and warehouses.
Refrigeration and industrial plants.
Parking garages and auto/truck maintenance facilities.
Oil and gas industry leak detection.

Technical Sheets

Instruction Manual

Catalog Page

Specifications

ACI Q8/B8 SERIES | EXPLOSION-PROOF BACnet & MODBUS DETECTORS – KEY SPECIFICATIONS

Power: 24 VDC/VAC nominal; 0.3A max consumption.
Outputs:
- Q8: 4-20 mA, 1-5 VDC, 2-10 VDC, and RS-485 Modbus/Optomux.
- B8: RS-485 BACnet MS/TP.
Relays: Three SPDT Form 1C dry contacts (1.0A @ 30 VDC).
Sensors: Electrochemical (toxic/O2), Catalytic Bead/NDIR (combustible), or PID (VOCs).
Enclosure: Cast aluminum with epoxy coating; NEMA 4X (IP66) rating.
Certifications: CSA Class I, Div 1 & 2; Groups A, B, C, D; Class II & III.
