Model XWA11V Walk-In Temp / Door /Alarm / Light Module

Category: Temperature

• Hi/Low temperature alarms w/delays

• Lighting management – Auto on/Auto off

• Door open alarm

• Panic alarm option

• Saves energy

• 120VAC direct power – UL Listed

• 8A alarm relay

• 16A light relay

• Battery back-up option

• Phone dialer option

• Loud outboard buzzer option

• J-Box or wall mounting box option

• Adjustable settings – optional programming HOT KEY

Technical Sheets

XWA11V Kit includes

• 8Ft. probe (can be extended to 300ft.)

• 9V Battery back-up harness (battery not included)

• Loud outboard buzzer

• Pre-wired

• Wall Mounting Box

• SST waterproof switch plate

• Magnetic Door Switch

XWA11V-4N0F0 J-Box mount

• 1 probe input

• 2 Relay outputs: 8A Alarm + 15A Lights

• 2 Digital Inputs (Door Switch + Def /Occupancy/Light)

• SST Switch plate cover

• 120Vac power UL listed

• Waterproof IP65
