DWYER DCP100A & DCP200A | PRESSURE MODULES FOR DCT1000 TIMER CONTROLLER

The Dwyer Series DCP100A/DCP200A pressure modules enable on-demand cleaning for DCT1000 dust collector timers. Features 4-20 mA output and 10″ or 20″ w.c. ranges. These modular pressure sensors transform standard timer boards into intelligent on-demand cleaning systems. By plugging directly into the master controller, they allow for real-time differential pressure measurement across dust bags or cartridges. The modules eliminate the need for expensive external transmitters by providing an integrated, isolated 4-20 mA readout channel. They are available in two standard ranges: 10″ w.c. (DCP100A) and 20″ w.c. (DCP200A), providing the necessary feedback for high and low limit control to optimize filter life and compressed air usage.

PRODUCT USES:

• On-Demand Dust Collection: Automating pulse-jet cleaning cycles based on real-time filter differential pressure.
• Remote Pressure Monitoring: Utilizing the 4-20 mA output to track baghouse performance from a central control room.
• High/Low Limit Control: Setting precise pressure thresholds for the start and stop of cleaning sequences.
• System Protection: Triggering alarms when differential pressure exceeds safe operating limits.
